Description
Limescale protection all-rounders
- Universal filter system for water optimisation in the gastronomy sector
- Protection of the machine technology against limescale deposits, particles, off-flavour components and chlorine
- Simple installation via universal BWT besthead FLEX connection technology
- Economic use for any water requirements thanks to numerous filter sizes
- Space-saving design that is very easy to handle
- Ensures best protection of technical equipment and the quality of all products made using it
Product details
BWT bestmax is the simple and practical all-round filtration solution developed for the numerous requirements in gastronomy. For unique coffee water, ideal water for vending machines and optimal pure steam for ovens and combination steamers. Thanks the new High-Efficiency-Technology (HET), water optimisation is even more efficient. The result: consistently high quality of all hot and cold beverages in cups and mugs, in the kitchen and in the bakery, for all foods and baked goods.
Technical advantages of BWT bestmax at a glance
- 5-stage filtration
- Highly efficient limescale protection
- Activated charcoal fleece for consistently crystal-clear water
- Filtration, also of bypass water
- Ease of handling when replacing the filter
- Horizontal or vertical installation
Technical details
| BWT bestmax type | X |
S | V | M | L | XL | 2XL |
| Filter head | besthead FLEX | besthead FLEX | besthead FLEX | besthead FLEX | besthead FLEX | besthead FLEX | besthead FLEX |
| Connection thread (in/out), (1) |
variable | variable | variable | variable | variable | variable | variable |
| Inlet pressure, min. – max. in bar |
2-8 | 2-8 | 2-8 | 2-8 | 2-8 | 2-8 | 2-8 |
| Water temperature, min. – max. in °C |
4-30 | 4-30 | 4-30 | 4-30 | 4-30 | 4-30 | 4-30 |
| Ambient temperature, min. – max. in °C |
4-40 | 4-40 | 4-40 | 4-40 | 4-40 | 4-40 | 4-40 |
| Total height without bracket (A) in mm, approx. | 280 | 360 | 420 | 475 | 500 | 500 | 574 |
| Total height with bracket (B) in mm, approx. | 300 | 385 | 445 | 500 | 530 | 530 | 600 |
| Connection height (C) in mm | 230 | 310 | 370 | 425 | 450 | 450 | 520 |
| Distance to floor (D) in mm | 65 | 65 | 65 | 65 | 65 | 65 | 65 |
| Installation length (E) in mm | 125 | 125 | 125 | 125 | 125 | 125 | 125 |
| Ø filter cartridge (F) in mm | 88 | 88 | 115 | 130 | 145 | 145 | 185 |
| Weight in kg, approx. (dry/wet) | 0.5/1.1 |
0.9/1.5 | 2.1/3.2 | 2.4/4.2 | 3.4/5.9 | 3.8/6.0 | 7.5/11.0 |
